1-1/2" Grid Clamp with Junior Receiver - S-Handle (6-Pack)
6-Pack Value Bundle — 1-1/2" Grid Clamp with Junior Receiver (S-Handle). Includes 6x individual clamps [RGC-JRASH-020] at 30% savings ($520.80 total).
6-Pack Bundle: Includes 6x 1-1/2" Grid Clamps (S-Handle) at 30% savings ($86.80/unit eq.).
SKU:
RGC-JRZSH-112
PRO GRIP 6-PACK VALUE BUNDLE — SAVE 30%
Equip your grip truck or soundstage overhead grid with six (6) heavy-duty 1-1/2" Grid Clamps with 1-1/8" Junior Receivers and Ergonomic S-Handles. Designed for professional film, television, and commercial production environments requiring ultra-secure pipe and truss rigging.
Looking for a single clamp? View the individual 1-1/2" Grid Clamp with Junior Receiver - S-Handle (Single Unit).
Engineering Fact Sheet
The Norms Studio RGC-JRZSH-112 is a professional-grade cinema rigging clamp engineered to attach 1-1/8" (28mm) Junior pin fixtures directly to standard 1-1/2" nominal schedule 40 pipe (1.900" / 48.3mm outer diameter) or trussing. Constructed from high-tensile 6061-T6 extruded aluminum with grade 8 steel fasteners and an ergonomic S-Handle tightening bolt for rapid hand-tightening without tools.
Technical & Mechanical Specifications
| Specification | Technical Value / Parameter |
|---|---|
| SKU / Internal Ref | RGC-JRZSH-112 (6-Pack Bundle) |
| Base Single SKU & Product Link | 6× RGC-JRASH-020 (Single Clamp) |
| Pipe Diameter Compatibility | Fits 1.5" Nominal Schedule 40 Pipe (1.90" / 48.3mm OD) & Standard 2" Trussing |
| Receiver Socket Standard | 1-1/8" (28mm) Junior Female Receiver with Brass Pressure Pad & Safety Pin Lock |
| Tightening Handle Style | Ergonomic Cast Aluminum S-Handle (T-Bolt) for maximum leverage and hand torque |
| Safe Working Load (SWL) | 1,100 lbs (500 kg) Vertical Hanging Load Limit per clamp |
| Material & Finish | 6061-T6 Extruded Aluminum Alloy, Anodized Silver/Clear Finish, Zinc-Coated Steel Hardware |
| Warranty Coverage | Norms Studio Standard Hardware Warranty (View Warranty Terms) |
Mechanical Rigging Safety & Torque Physics
The S-Handle mechanism provides optimized torque leverage (Torque = Radius x Force), allowing grip technicians to achieve secure clamping friction on anodized aluminum or steel grid pipe without requiring spanners or tools. Always inspect pipe outer diameter and ensure the junior receiver safety pin is engaged before suspending overhead payloads.
